GENERAL

Built: Tuong Aik, Malaysia 2003
Flag: Nigeria
Classification: B.V. 13/3 (E) Tug, Deep Sea Vessel, Unrestricted Service
Call Sign: 5NZS
Port of Registry: Lagos



TONNAGE

GNT: 299 tons
NRT: 89 tons
DWT: 254 tons



ACCOMMODATION: 20 PERSONNEL

Cabins: 2 × 1 | 3 × 2 | 3 × 4



MAIN DIMENSIONS

Length Overall: 36.00m
Breadth Muld: 9.00m
Draft: Design Loaded 3.25m
Depth Muld: 4.00m
Free Deck space: 16 × 5.7m 91m2



TANK CAPACITY

Marine Gas Oil: 205m3
Fresh Water: 76 tons
Ballast Water: 23m3
Dirty: 4m3



SAFETY EQUIPMENT

Life Raft: 2 × 25 men inflatable Life raft



TOWING

Anchor windlass: Electric 5.0 ton @ 10m/min
24mm × 275m chain
Anchors: 2 × 550 kg



MACHINERY

Main Engines: 2 × Cummins KTA 38 M1
Total Horse Power: 2,000 BHP
Bow Thrusters: 3T thrust
Propulsion: Twin variable pitch in kort nozzles
Generators: 2 × 85 Kw Caterpillar 3304B 415/3 50 Hz



RADIO AND NAVIGATION EQUIPMENT

Radars: 1 × JRC NCD-500 .
GPS: 1 × JRC J-NAV-500
Compass: 2 × Daiko Keiki T 150B
VHF: JRC VHF-200
S.S.B: JRC JBS-196



SPEED AND CONSUMPTION

Maximum Speed: 12 knots
Range: 21 Days



MISCELLANEOUS

Sewage Treatment Plant
Separate Cooler and freezer for Charters use
Deck Store
